Good technical drawings reduce risk.

Here at Delta, we understand the importance of technical drawings.  Our bank of new technical drawings, visually communicate effectively how our waterproofing management systems function, are drafted according to industry standards and offer visual advice how they should be constructed having been produced by our experienced and knowledgeable Technical Team.

We have given consideration to how our technical drawings can be accessed, using a professional drafter, FastTrackCAD, we have bridged the gap between manufacturer and engineer.  Our technical drawings are available in easy to download DWG and PDF formats.

Technical drawings are essential for communicating an effective installation process.  Delta’s technical drawings are unambiguous and easy to understand offering clear and precise measurable description.  Delta’s Technical team has accurately and unambiguously captured all the geometric features of our products and components to convey support.

Delta understands the need for precise communication in the preparation of a functional waterproofing design.  Our technical drawings distinguish correct installation methods as specified in British Standard 8102:2009 (Code of Practice for Protection of Below Ground Structures Against Water from the Ground).

Our drawings have been categorised into 11 sections:

  • Type A – Barrier Protection
  • Type B – Integral Protection
  • Type C – Drained Protection
  • Type D – Combined Systems
  • Type E – External Waterproofing
  • Type F – Detailed Ancillaries
  • Decks (Terrances/Green Roofs/DWD)
  • FoamGlass
  • Gas Protection
  • Damp Proofing
  • Pumps and Drainage

To further assist we have set up a letter system to help with ease of reference:

  • Type A – Barrier Protection (A)
  • Type B – Integral Protection (B)
  • Type C – Drained Protection (C)
  • Type D – Combined Systems (D)
  • Type E – External Waterproofing (E)
  • Type F – Detailed Ancillaries (F)
  • Decks (Terrances/Green Roofs) (DWD-D)
  • FoamGlass (C)
  • Gas Protection (DGS)
  • Damp Proofing (DDP)
  • Pumps and Drainage (DPP)

Information from our Technical Drawings can be directly incorporated into Architects Designs, saving time.

Delta Membrane Systems Limited is the leading Type C Cavity Drain Membrane manufacturer in the United Kingdom.  Our extensive range of waterproofing and damp proofing products are suitable for basement drainage and structural waterproofing (both for new build and existing structures) and in flood resilience.

Installing a Delta Membrane System offers complete protection to structures from water ingress.  Our products comply with British Standard 8102:2009 and are BBA Certified.  Our dedicated technical team offer knowledge and experience in waterproofing design solutions, on site assistance and advice throughout a project.

A waterproofing management system will only fail due to poor design or poor installation, with Delta Membrane Systems onboard we can ensure a fully functional waterproofing management system. Our unlimited site support, installation training and quality control are second to none.
